Product Data

Material Data

Please click here for Material Safety Data Sheet (MSDS) PDF

PHYSICAL DATA

Standard Size -	2400 mm x 600 mm – with square edges. Pallet stacked
Standard Thickness -	25 mm, 38 mm, 50 mm
Weight of Woodtex -	12 kg/m2, 17 kg/m2, 22 kg/m2
Visual Finish -	Natural coarse grain, with one side having a factory planed finish.

FIRE RESISTANCE DATA

AS/NZS 1530.3	:Fire Indices	:0,0,0,0
AS/NZS 3837	:Fire Resistance	: Group 1
AS/NZS 1530.4	:Fire Rating Level	:FRL N/A

ESD DATA

Volatile Organic Content	: VOC = Nil
Ozone Depleting Product	: ODP = Nil
Timber source	: Sustainable plantations only

ACOUSTIC DATA WOODTEX Absorption Coefficients

25mm directly fixed to solid substrate	: NRC 0.40
38mm directly fixed to solid substrate	: NRC 0.45
50mm directly fixed to solid substrate	: NRC 0.52
25mm with 50 mm airspace behind	: NRC 0.45
38mm with 50 mm airspace behind	: NRC 0.51
50mm with 50 mm airspace behind	: NRC 0.66
25mm, 40mm airspace with 25mm high density polyester	: NRC 0.65
38mm, 40mm airspace with 25mm high density polyester	: NRC 0.70
50mm, 40mm airspace with 25mm high density polyester	: NRC 0.75
25mm, 65mm airspace with 50mm high density polyester	: NRC 0.70
38mm, 65mm airspace with 50mm high density polyester	: NRC 0.80
50mm, 65mm airspace with 50mm high density polyester	: NRC 0.82

WOODTEX Insertion Loss Estimates

(Woodtex stand alone, with no backing) –	25mm – Rw 22 38mm – Rw 26 50mm – Rw 30
(Woodtex with 6mm fibre cement backing) –	25mm – Rw 28 38mm – Rw 32 50mm – Rw 38
